Help files for Beta testing Cool Lutherie software
Here are links to help files for projects that I make available through CoolLutherie.com
This page is a work in progress while the software, as well as the hosting website, is going through beta testing and development. If you discover any issues, please contact me: at jeffwhitehead.com Thank you!
Analog To MIDI Translator (Monophonic)
Application: AMT(M).app
Current Version: 1.3
The Analog to MIDI Translator (Monophonic) - AMT(M).app - is a an application that translates audio from a guitar or violin to MIDI version 1. This enables you to play software synthesizers as monophonic instruments. The application also provides a network connection to TouchDesigner. The software download includes an example TouchDesigner file to get your started.
Open the document: AMT(M) Version 1 Help
Get the software: Audio to MIDI Monophonic Translator Download (DMG file)
Analog To MIDI Translator (Polyphonic)
Application: AMT(P).app
Current Version: 1.3
The Analog to MIDI Translator (Polyphonic) - AMT(P).app - is a companion program to the breakout board projects. A breakout board takes the 13-pin DIN cable (used by hexaphonic pickups such as Roland's GK-3 and Graph Tech's Ghost system) and splits each string's pickup into a separate audio output. This system enables you to play polyphonic, software synthesizers in MIDI version 2 and MIDI version 1. In MIDI 2, the application includes modulation and aftertouch controls, utilizing MPE (MIDI Polyphonic Expression). The application also provides a network connection to TouchDesigner that supports the polyphonic data. The software download includes an example TouchDesigner file to get your started.
Open the document: AMT(P) Version 1 Help
Get the software: Audio to MIDI Polyphonic Translator Download (DMG file)
Get the Polyphonic TouchDesigner example: TouchDesigner example "Swirling Leaves" Download (ZIP file)
Stacker for AMT(P)
Application: AUGuitarStacker.app
Current Version: 1.0
Stacker is an Audio Unit plugin host that compliments the AMT(P) application. It supports the simultaneous playing of 5 MIDI plugin instruments from the MIDI output of AMT(P) and 3 audio plugins (like amplifier emulators) from the analog pickup output. Stacker supports up to 20 settings. For each AU, it supports up to 10 presets.
Open the document: work in progress
Get the software: AU Guitar Stacker Download (DMG file)
Remote Control for Stacker
Application: StackerController.app
Current Version: 1.0
The Stacker Controller enables you to rapidly select settings and plugin presets over a local network or on the same computer. It provides a matrix interface that simplifies the selection of complex combinations of plugins and their presets, reducing the selection task to a single click for real time switching while playing.
Open the document: work in progress
Get the software: Stacker Controller Download (DMG file)
Polyphonic Emulator
Application: AMT(P)Emulator.app for Mac, AMT(P)Emulator.exe for Windows
Current Version: 1.0
The Polyphonic Emulator replicates the MIDI and JSON output of the AMT(P) application through a simple interface, obviating the need for a guitar or violin setup while creating TouchDesigner networks that respond to a live performance. The application enables a visual artist to simulate the output which would come from AMT(P) during a performance by a guitar or violin, decoupling their design process from the actual instrument. It is provided as a Max MSP application for Windows or a Max project with an example TouchDesigner network, enabling artists to work in either a Mac or Windows environment. The emulator requires Max version 9. (https://cycling74.com)
Open the help document: work in progress
Get the Windows software: Windows AMT(P) Emulator Download (ZIP file)
Get the Max MSP project files (Mac or Windows): Max Project - AMT(P) Emulator (ZIP file)
Get the Polyphonic TouchDesigner example: TouchDesigner example Download (ZIP file)
